ENTERPRISE DATA CENTER MAINTENANCE AND OPEX ESTIMATOR

INPUT YOUR SPECIFIC NEEDS IN THE FIELDS BELOW FOR THE MOST ACCURATE INFORMATION.

INFRASTRUCTURE CONFIGURATION

Actual Critical IT Load

?
Power as read at the UPS output.
kW

IT White Space

?
Square footage of the actual computing space of the data hall not including external support spaces like UPS rooms or equipment galleries.
ft2

Current Power Density

?
A data hall can range from 100 – 300 W/SF. A 2021 survey from the Uptime Institute indicates 36% of data centers operators are below 10kW per rack and 36% of operators are between 10-19 kW per rack. Only 12% of users are above 30 kW per rack. Data also show an inverse relationship between rack density and annualized PUE.
W/ft2

Current Electrical Rate if known

?
Average utility costs by region can be found on the U.S. Energy Information Administration website here.
$/KWH

GEOGRAPHY / PROFILE

LOCATION

City

ELECTRICAL TOPOLOGY

UPS Redundancy

?
Uptime Institute’s 2020 global survey show a shift away from 2N and a shift towards N+2.

2N: 34%
N+2: 16%
N+1: 47%
N: 3%

Generator Redundancy

MECHANICAL TOPOLOGY

Heat Rejection Type

?
In 2018, data centers used 135.5 billion gallons of water

Plant Redundancy

?
Use of availability zones and multisite resiliency has decreased data center cooling redundancy in 2020.

2N: 11%
N+2: 19%
N+1: 65%
N: 5%

Estimated Annualized PUE

?
Power Usage Effectiveness (PUE) = (Total Facility Energy) / (IT Equipment Energy). Uptime institute’s 2021 survey indicates that respondents’ average annualized PUE globally was 1.57 while the average in 2011 was 1.98.
Fill out the form below to receive your OPEx Forecast Results.
